功能及特点 Function and characteristics
该设备完全替代人工笔涂，确保每档皮辊涂刷均匀。配置的胶液补充系统，
让笔头存容量每次精准。
涂刷后的皮辊保留在V口槽内可固一定的时间后出料。
配置有吸味风机外排胶水味。
The device completely replaces the manual pen coating to ensure that
every roll is evenly coated.
The configuration of the glue refill system, so that the pen storage
capacity is accurate every time. After brushing, the roller can be retained in the
V-groove for a certain time before discharging. Equipped with suction
fan exhaust glue smell.
技术参数及规格 Technial Parameters
电源 power supply 220V+PE(单相三线制) single-phase three-wire system
整机功率 Total power 300W
涂刷方式 Painting method 笔式 pen type
胶液补充方式 Glue filling method 定量自动（可设置）
automatic quantitative (can be set)
涂胶胶液容量 Adhesive liquid capacity ≤70ml
待处理皮辊装容量 Roller capacity to be processed 108档/stops
待干皮辊区域 Roller area to be dried 4档/stops
涂胶产量 Gluing output 600档/小时 speed/hour
适用处理皮辊 Suitable for handling roller 粗细纱、紧密纺皮辊
thick and fine yarn, tight spinning roller
控制方式 Control mode 人机触摸界面 man-machine touch interface
排味风机风量 Air capacity of exhaust fan 310立方/小时cubic meters/hour
